Dual power hybrid equipment working principle:
1. the dual power mixing equipment due to the 360-degree non-dead Angle movement of the barrel superposition of the internal full-size blade stirring shear movement, so that the powder particles along the cone wall for the surrounding operation and convection, stirring movement, so that powder mixing becomes more uniform and easy.
2. Due to the autobiography of the full-size blade assembly, the powder is discharged to the center of the cone for radial movement, and there is also shear convection movement to achieve uniform mixing of various powders.
3. the powder of the dual-power mixing equipment from the bottom of the cone upward flow and discharge to the external surface of the internal mixing component, the material mixing, which is the so-called shear doping mixing, is very important for the uniform supply of powder.
4. The downward flow of powder particles caused by the rotation of dual-power mixing equipment is precisely due to the combination of spiral rotation in the mixing equipment, which forms four flow forms of powder: convection, shear, diffusion and infiltration. Therefore, the powder can quickly achieve uniform mixing in the mixing equipment.
Advantages of dual-power hybrid equipment:
1. dual-power mixing equipment adopts dual-power superposition mixing process, low mixing speed and mild mixing process; No segregation is produced, and the original physical state of the material is not destroyed. For the large discipline of powder mixing, no matter which industry is the current new, mixing fast, mixing efficient mixing equipment. Compared with the three-dimensional mixer, spiral belt mixer and trough mixer in the industry, the mixing equipment has the characteristics of strong mixing ability, high precision, fast speed, small residue, low energy consumption, wide application range, etc. The mixing equipment is not affected by the specific gravity of the material and the particle size shape.
2. efficient dual-power mixing equipment for micro powder mixing is also a great advantage, such as the proportion of powder in the pharmaceutical industry as small as 1: At 10000, or when the liquid addition amount is more than 20%, it can ensure uniform mixing, and its energy consumption per ton is about 30% lower than that of the trough mixer, the variation coefficient of mixing uniformity CV< 5%, up to 3%, each batch of mixing time 30-120s, and the proportion of filling volume is large, which significantly reduces the mixing cycle and improves production efficiency.
